The Gazelle Ultimate family offers award-winning design and is built for riders who want to move faster without sacrificing comfort. With pedal assist up to 20 and 28 mph, a more upright riding position, wide tires, front suspension, and trusted Bosch technology, it delivers confidence and control at speed.
FEATURES:
- Built for the real world: Wide Schwalbe tires, front suspension, ergonomic grips, and an adjustable riding position work together to absorb bumps and reduce fatigue. Whether you're navigating city streets, bike paths, or rough pavement, the Ultimate delivers a ride that feels stable, comfortable, and in control.
- Elegant integration: The Gazelle Ultimates are the end result of award-winning design centered seamless integration of the Bosch battery and motor and overall frame styling. This is an electric bike with serious curb appeal. The Ultimate is delightfully stable on the road thanks to a low centre of gravity and the stiffness of the frame.
- Power and performance: Propelled by Bosch's latest generation motor systems, pedal-assistance is powerful and responsive, acutely adjusting to riders' effort and changes in incline. Even the steepest hills can be neutralized by the high-torque with the Performance Line Speed motors. Depending on the model, riders can unlock up to 90Nm of torque through the Bosch Flow app for even stronger acceleration, easier climbing, and a more responsive ride.
- 10 speed derailleur
- Bosch Active Line Plus (60 Nm)
- Class 1 e-bike
- Battery 540Wh
- Bosch Purion 200 side display
- Hydraulic disc brakes
- Knobby tires
- 60 lux headlight
SPECS:
| Frame | Stable aluminum frame with 70,5° headset angle and 71,5° saddle tube angle |
|---|---|
| Fork | SR Suntour NVX32 Air, Telescope, air, 80 mm travel |
| Rear Shock | N/A |
| Rims/Wheels | Ryde ZAC 25, double-walled aluminum |
| Hubs | Front: Shimano HB-TC500 / Rear: Shimano QC300 |
| Spokes | N/A |
| Tires | Schwalbe Smart Sam, 54-622 |
| Crankset | N/A |
| Chainrings | 42 |
| Bottom Bracket | N/A |
| Chain | KMC E500EPT, rust protective coating |
| Front Derailleur | N/A |
| Rear Derailleur | Shimano Deore |
| Cassette/Rear Cogs | 11-42 |
| Shifters | Shimano Deore M6000 |
| Handlebars | aluminum, slightly curved |
| Stem | Adjustable stem with Intelli-Mount interface |
| Brakes | Shimano BR-MT200 hydraulic disc brake, 180 mm front / 160 mm rear, 2 piston |
| Pedals | N/A |
| Saddle | Selle Royal Essenza Plus |
| Seat Post | 31,6 mm, Suspension |
| Motor | Bosch Smart System Active Line Plus, 60 Nm |
| Battery | 540 Wh, integrated in the frame |
| Display/Controller | Bosch Purion 200 |
| Max Assisted Speed | Class 1, 20 mph |
| Charger | Bosch Compact Charger, 2A |
| Extras | aluminum MIK HD system carrier, Ergon GPI-L grips, Herrmans MR9 front light, Spanninga Commuter Glow rear light, Axa Imenso L lock, Ursus Mooi drop-down rear stand |
*Product specifications are subject to change without notice.
*Certain battery-embedded products are subject to a one-time, non-refundable Advanced Recycling Fee (ARF) at purchase, as required by California SB 1215 and administered by Call2Recycle. For 2026, the ARF is set at 1.5% of the item price, capped at $15 per item.
