The Gazelle Ultimate family offers award-winning design and is built for riders who want to move faster without sacrificing comfort. With pedal assist up to 20 and 28 mph, a more upright riding position, wide tires, front suspension, and trusted Bosch technology, it delivers confidence and control at speed.
FEATURES:
- Stepless Enviolo gearing
- Bosch Performance Line Sport (90 Nm)
- Class 3, 28 mph
- 540Wh battery, 50 miles range
- Bosch Purion 200 display
- Kiox 500 colour display with navigation
- Low-maintenance belt drive
- 90 lux headlamp
SPECS:
| Frame | Stable aluminum frame, Low-Step / High-Step |
|---|---|
| Fork | SR Suntour MOBIE 34, aluminum, Telescope, air, 80 mm travel |
| Rear Shock | N/A |
| Rims/Wheels | Ryde ZAC 25, double-walled aluminum, 28" |
| Hubs | Shimano [F] / Enviolo Trekking Manual [R] |
| Spokes | N/A |
| Tires | Schwalbe The Green Marathon, 55-622 |
| Crankset | N/A |
| Chainrings | 55T, Gates CDX |
| Bottom Bracket | N/A |
| Chain | Gates CDX belt |
| Front Derailleur | N/A |
| Rear Derailleur | Enviolo Trekking Manual |
| Cassette/Rear Cogs | 22T, Gates CDX |
| Shifters | N/A |
| Handlebars | Aluminum, slightly curved |
| Stem | Adjustable |
| Brakes | Shimano MT420, hydraulic disc brake, 180mm [F] / 160mm [R], 4-piston |
| Pedals | N/A |
| Saddle | Selle Royal Essenza Plus Gel |
| Seat Post | Suspension |
| Motor | Bosch Performance Line Sport, 85Nm, Mid |
| Battery | Bosch Intube 540 Wh, 36V, 15 Ah |
| Display/Controller | Bosch Purion 200, Colour |
| Max Assisted Speed | 28 mph |
| Charger | Bosch Standard Charger, 4A |
| Extras | Herrmans MR10 front light, Spanninga Commuter Glow rear light, aluminum MIK HD system carrier, Axa lock, Ursus Mooi drop-down rear stand, Chain guard |
*Product specifications are subject to change without notice.
