Profile Design

Sonic Ergo 52a Aerobar

RHSNC521

$190.00
/
Pay using HSA/FSA with flex Select Flex at checkout to check your eligibility paying with your HSA/FSA card for your items

California Region

  • San Rafael 2-4 days 10-14 days
  • Sausalito 2-4 days 10-14 days
  • Berkeley 2-4 days 10-14 days
  • Palo Alto 2-4 days 10-14 days
  • San Francisco 2-4 days 10-14 days
  • Sacramento 2-4 days 10-14 days
  • Los Gatos 2-4 days 10-14 days
  • Petaluma 2-4 days 10-14 days
  • Walnut Creek 2-4 days 10-14 days
  • San Jose 2-4 days 10-14 days
  • Pleasanton 2-4 days 10-14 days
  • Folsom 2-4 days 10-14 days
  • Roseville 2-4 days 10-14 days
  • Stanford Research Park 2-4 days 10-14 days
  • Distribution Center 2-4 days 10-14 days
  • Distribution Center 2-4 days 10-14 days

Colorado Region

  • Denver East 2-4 days 10-14 days
  • Denver Downtown 2-4 days 10-14 days
  • Highlands Ranch 2-4 days 10-14 days
  • Parker 2-4 days 10-14 days
  • Boulder Available
  • Distribution Center 2-4 days 10-14 days

Enjoy FREE shipping on all orders over $99! Orders under $99 ship for just $7.95.

All bikes ship FREE, including top brands like Cannondale, Santa Cruz, Cervelo, Gazelle, and Pivot. For the best ride-ready experience, our Gold Label Assembly service is automatically added at checkout for only $79 (regularly $100). This ensures your bike is professionally built, tested, and expertly re-packaged by our certified technicians—It's bike shop quality, direct to your doorstep.

Some bikes may be ineligible for shipping due to manufacturer restrictions.

Shop with confidence! It's important to us that you are happy with your Mike’s Bikes purchase so we offer offer a 30-day return/exchange window for your unused gear and 14 days on all bikes. Our exchange and return process is fast and easy. If you choose to exchange for a different size or color, we will ship your product for free.

View Full Policy

The Sonic bracket offers an extensive fit range, low weight and easy adjustment along with minimal frontal area. Combining this with the Ergo armrest creates an aerobar that will aid most riders in optimizing their position for both speed and comfort.

The 52A is one of the newest versions of our reliable aluminum extension range.

FEATURES:

  • Performance: The Sonic/Ergo is designed to present minimal frontal area to create as little aerodynamic drag as possible. The main purpose of an aerobar is, of course, to get the rider into a fast position despite a fairly minimalist appearance the Sonic/Ergo offers a comprehensive fit range for exactly this purpose.
  • Fit Data: The 52a extensions have a 52° for the grip. The rider can choose whether to hold high for the shrugged position or low for a more open, head up position.
  • Armrest Offset: -70mm to -17.5mm in 7.5mm steps
  • Armrest Width: 124mm to 290mm in 18.5mm steps (With Extensions at 100mm)
  • Armrest Stack:  60mm (no riser kit) to 130mm in 5mm increments (With aftermarket Riser Kit)

SPECS:

  • Bracket: Sonic
  • Clamp Diameter: 31.8mm or (26.0 with Shim Kit - Shim Kit is sold separately)
  • Armrest:  Ergo / 10mm Pads
  • Armrest Width: 124mm to 290mm in 18.5mm steps (with Extensions at 100mm)
  • Armrest Offset: -70mm to -17.5mm in 7.5mm steps
  • Armrest Stack: The minimum is 60mm and the bracket is compatible with our existing risers which add up to 130mm stack with (70mm of spacers added)
  • Construction: 6061-T6 aluminum, pre-drilled for bar-end shifter cable routing
  • Extension Length: 400mm
  • Extension Angle: 52 Degrees
  • Extension Rise: 87mm (bottom to top)
  • Extension Offset: 15mm total
  • Outer Diameter: 22.2mm
  • Inner Diameter: 19.2mm
  • Shifter Compatibility: Electronic or Mechanical
  • Color: Anodized Matte Black
  • Weight: 564g
  • Bar Clamp: 6Nm (53 inlbf)
  • Extension Clamp: 6Nm (53 inlbf)
  • Armrest Bolts: 4.7Nm (42 inlbf)
  • Bracket: 234g
  • Armrest: 130g
  • Extensions: 222g
  • Total: 586g
